Konica-Minolta bizhub Pro 1050eP Error Codes


Select an Error Code or Type an Error Code to begin searching

Error


Have a better picture? Update the product image. PNG Only. Open a new private window or clear your cache to see the new image.


Konica-Minolta bizhub Pro 1050eP Top Searches

These results are ranked by popularity.

Error
SC23-01Description: The speed error signal of the toner bottle motor (M6) is checked. An error detection signal is detected twice in succession a specified period of time after the M6 turns ON (the first signal is ignored).
SC76-32Description: The shift unit home sensor (PS11) does not turn OFF within a specified period of time after the shift unit motor (M5) of the tandem (2nd) LS turns ON. Or, the PS11 does not turn ON within a specified period of time.
SC53-16Description: The blowout of a fuse for the SD/ CL in the PF is detected 2. The blowout of a fuse for the SD/CL in the PF drive board (PFUDB) is checked. At the start, an error detection signal (blowout of a fuse for the solenoid/motor) is detected. Howev
SC50-02Description: Main body drive serial input abnormality 2. In the I/O initial communication check in the printer control board (PRCB) from the power on ACK, a serial data is not received from the main body drive unit within a specified period of time.
SC46-16Description: Compression device access abnormality. When writing images, in spite of no resource provided, an inappropriate processing such as an access to the compression device is made.

Konica-Minolta bizhub Pro 1050eP Common Errors

The most common error codes.

Error
SC23-01Description: The speed error signal of the toner bottle motor (M6) is checked. An error detection signal is detected twice in succession a specified period of time after the M6 turns ON (the first signal is ignored).
SC76-32Description: The shift unit home sensor (PS11) does not turn OFF within a specified period of time after the shift unit motor (M5) of the tandem (2nd) LS turns ON. Or, the PS11 does not turn ON within a specified period of time.
SC53-16Description: The blowout of a fuse for the SD/ CL in the PF is detected 2. The blowout of a fuse for the SD/CL in the PF drive board (PFUDB) is checked. At the start, an error detection signal (blowout of a fuse for the solenoid/motor) is detected. Howev
SC50-02Description: Main body drive serial input abnormality 2. In the I/O initial communication check in the printer control board (PRCB) from the power on ACK, a serial data is not received from the main body drive unit within a specified period of time.
SC46-16Description: Compression device access abnormality. When writing images, in spite of no resource provided, an inappropriate processing such as an access to the compression device is made.
SC46-16Description: Compression device access abnormality. When writing images, in spite of no resource provided, an inappropriate processing such as an access to the compression device is made.
SC32-30Description: The rotation of the paper feed assist fan /Rr2 (FM23) is checked, and the 24V power source is also checked. An abnormal condition occurs with the FM23 EM signal a specified period of time after the FM23 is turned ON. This abnormal condition
SC50-02Description: Main body drive serial input abnormality 2. In the I/O initial communication check in the printer control board (PRCB) from the power on ACK, a serial data is not received from the main body drive unit within a specified period of time.
SC23-01Description: The speed error signal of the toner bottle motor (M6) is checked. An error detection signal is detected twice in succession a specified period of time after the M6 turns ON (the first signal is ignored).
SC35-02Description: Thermistor /3 (TH3) low temperature detection (software). The TH3 does not get to 50°C when a specified period of time elapses after the main switch (SW1) is turned ON for the fusing ON control.
